| Part NO. |
Nominal Inductance(nH/N²) |
Weight
(g) |
Path Length
(cm) |
Cross Section Area
(cm²) |
Dimensions(mm)
OD(Max) X ID(Min) X HT(Max) |
Package Unit (pcs/box) |
PDF
File |
| 026 |
060 |
075 |
090 |
125 |
Before Finish |
After Finish |
| WK031 |
11 |
20 |
25 |
31 |
37 |
0.80 |
1.787 |
0.0615 |
7.87x3.96x3.18 |
8.51x3.43x3.81 |
16K |
 |
| WK040 |
14 |
26 |
32 |
40 |
48 |
1.79 |
2.38 |
0.1 |
10.16x5.08x3.96 |
10.80x4.57x4.57 |
8K |
|
| WK044 |
11 |
21 |
26 |
32 |
38 |
1.81 |
2.69 |
0.0906 |
11.18x6.35x3.96 |
11.90x5.89x4.72 |
6K |
|
| WK050 |
12 |
22 |
27 |
34 |
40 |
2.69 |
3.12 |
0.114 |
12.70x7.62x4.75 |
13.46x6.99x5.51 |
4K |
|
| WK065 |
15 |
29 |
35 |
43 |
52 |
6.0 |
4.11 |
0.192 |
16.51x10.16x6.35 |
17.40x9.53x7.11 |
1960 |
|
| WK068 |
19 |
35 |
43 |
53 |
64 |
7.1 |
4.14 |
0.232 |
17.27x9.65x6.35 |
18.03x9.02x7.11 |
1960 |
|
| WK080 |
14 |
26 |
32 |
41 |
49 |
8.7 |
5.09 |
0.226 |
20.32x12.70x6.35 |
21.1x12.07x7.11 |
1368 |
|
| WK090 |
19 |
35 |
43 |
54 |
65 |
13.6 |
5.67 |
0.331 |
22.86x13.97x7.62 |
23.62x13.39x8.38 |
850 |
|
| WK092 |
22 |
42 |
51 |
63 |
76 |
16.8 |
5.88 |
0.388 |
23.57x14.40x8.89 |
24.30x13.77x9.70 |
750 |
|
| WK106 |
32 |
62 |
75 |
94 |
113 |
30.6 |
6.35 |
0.654 |
26.92x14.73x11.18 |
27.70x14.10x11.99 |
360 |
|
| WK130 |
28 |
50 |
61 |
76 |
91 |
40.4 |
8.15 |
0.672 |
33.02x19.94x10.67 |
33.83x19.30x11.61 |
240 |
|
| WK135 |
16 |
31 |
38 |
47 |
57 |
30.3 |
8.95 |
0.454 |
34.29x23.37x8.89 |
35.20x22.60x9.83 |
280 |
|
| WK141 |
24 |
46 |
56 |
70 |
84 |
45 |
8.98 |
0.678 |
35.81x22.35x10.46 |
36.70x21.50x11.28 |
240 |
|
| WK157 |
35 |
67 |
81 |
101 |
121 |
78 |
9.84 |
1.072 |
39.88x24.13x14.48 |
40.70x23.30x15.37 |
120 |
|
| WK184 |
59 |
112 |
135 |
169 |
202 |
156 |
10.74 |
1.99 |
46.74x24.13x18.03 |
47.60x23.30x18.92 |
72 |
|
| WK185 |
37 |
71 |
86 |
107 |
128 |
112 |
11.63 |
1.34 |
46.74x28.70x15.24 |
47.60x27.90x16.13 |
72 |
|
| WK200 |
32 |
60 |
73 |
91 |
109 |
114 |
12.73 |
1.25 |
50.80x31.75x13.46 |
51.70x30.90x14.35 |
96 |
|
| WK226 |
60 |
115 |
138 |
172 |
206 |
213 |
12.5 |
2.29 |
57.15x26.39x15.24 |
28.00x25.60x16.10 |
77 |
|
| WK225 |
33 |
62 |
75 |
94 |
112 |
154 |
14.3 |
1.444 |
57.15x35.56x13.97 |
58.00x34.70x14.86 |
88 |
|
| WK250 |
83 |
160 |
192 |
|
|
381 |
14.37 |
3.675 |
62.0x32.6x25.0 |
63.1x31.37x26.27 |
24 |
|
| WK740 |
89 |
171 |
206 |
|
|
656 |
18.38 |
5.04 |
74.1x45.3x35.0 |
75.2x44.07x36.27 |
15 |
|
| WK300 |
30 |
56 |
68 |
|
|
258 |
20 |
1.77 |
77.8x49.23x12.7 |
78.9x48.0x13.97 |
40 |
|
| WK306 |
37 |
70 |
85 |
|
|
323 |
20 |
2.77 |
77.8x49.23x15.9 |
78.9x48.0x17.2 |
35 |
|
| WK1013 |
40 |
92 |
192 |
|
|
548.6 |
24.27 |
2.97 |
101.6x57.2x13.6 |
103.1x55.7x14.9 |
12 |
|
| WK1016 |
47 |
112 |
228 |
|
|
665.6 |
24.27 |
3.52 |
101.6x57.2x16.5 |
103.1x55.7x17.8 |
12 |
|
| WK1027 |
80 |
184 |
384 |
|
|
1097.3 |
24.27 |
5.94 |
101.6x57.2x27.2 |
103.1x55.7x28.5 |
6 |
|
| WK1033 |
94 |
224 |
456 |
|
|
1331.3 |
24.27 |
7.04 |
101.6x57.2x33.0 |
103.1x55.7x34.3 |
6 |
|
| WK1320 |
54 |
124 |
259 |
|
|
1280.1 |
32.42 |
5.35 |
132.5x78.6x20.3 |
134.2x77.0x21.7 |
5 |
|
| WK1325 |
68 |
156 |
325 |
|
|
1601.7 |
32.42 |
6.71 |
132.5x78.6x25.4 |
134.2x77.0x26.8 |
4 |
|
| WK1333 |
88 |
202 |
422 |
|
|
2080.9 |
32.42 |
8.72 |
132.5x78.6x33.0 |
134.2x77.0x34.4 |
3 |
|
| WK1340 |
108 |
248 |
518 |
|
|
2560.8 |
32.42 |
10.69 |
132.5x78.6x40.6 |
134.2x77.0x42.0 |
3 |
|
| WK1625 |
80 |
184 |
384 |
|
|
2808.0 |
38.65 |
9.46 |
165.0x88.9x25.4 |
167.2x86.9x27.3 |
4 |
| | |
| 　 |
|
|
|
