MAGNETIC DIMENSIONS |
WEIPOSI
Part No. |
AL
nH/N2 |
OD
in/mm |
ID
in/mm |
Ht
in/mm |
cm |
A
cm2 |
V
cm3 |
|
T5-6 |
1.0 |
.050/1.27 |
.025/.64 |
.025/.64 |
.30 |
.0019 |
.0006 |
|
T5-10 |
.7 |
|
T5-17 |
.42 |
|
T5-0 |
.16 |
|
A |
|
T7-1 |
3.5 |
.070/1.78 |
.035/.89 |
.030/.76 |
.42 |
.0035 |
.0015 |
|
T7-2 |
1.5 |
|
T7-6 |
1.3 |
|
T7-10 |
.9 |
|
T7-12 |
.6 |
|
T7-17 |
.6 |
|
T7-0 |
.3 |
|
- |
|
T10-1 |
3.2 |
.097/2.46 |
.044/1.12 |
.030/.76 |
.56 |
.0045 |
.0025 |
|
T10-2 |
1.35 |
|
T10-6 |
1.15 |
|
T10-10 |
.8 |
|
T10-12 |
.5 |
|
T10-17 |
.5 |
|
T10-0 |
.24 |
|
- |
|
T12-1 |
4.8 |
.125/3.18 |
.062/1.57 |
.050/1.27 |
.75 |
.010 |
.0077 |
|
T12-2 |
2.0 |
|
T12-3 |
6.0 |
|
T12-6 |
1.7 |
|
T12-7 |
1.8 |
|
T12-10 |
1.2 |
|
T12-12 |
.75 |
|
T12-15 |
5.0 |
|
T12-17 |
.75 |
|
T12-0 |
.24 |
|
- |
|
T12-2B |
1.85 |
.125/3.18 |
.062/1.57 |
.042/1.07 |
.75 |
.008 |
.0061 |
|
T12-6B |
1.35 |
|
T12-10B |
1.0 |
|
A |
|
T16-1 |
4.4 |
.160/4.06 |
.078/1.98 |
.060/1.52 |
.93 |
.015 |
.0141 |
|
T16-2 |
2.2 |
|
T16-3 |
6.1 |
|
T16-6 |
1.9 |
|
T16-10 |
1.3 |
|
T16-12 |
.8 |
|
T16-15 |
5.5 |
|
T16-17 |
.8 |
|
T16-0 |
.3 |
|
- |
|
T18-6 |
.9 |
.185/4.70 |
.102/2.59 |
.040/1.02 |
1.14 |
.010 |
.0114 |
| |
| |
|
|
|
